What will you learn in Master SOLIDWORKS 3D CAD using real-world examples Course
Navigate the SolidWorks 2021 interface: Command Manager, Feature Manager, and customizable toolbars
Create fully defined 2D sketches and transform them into 3D features: Extrude, Revolve, Loft, Sweep, and Cut
Assemble multiple parts using mates, subassemblies, and motion studies to simulate real-world mechanisms
Generate professional 2D drawings with standard views, dimensions, annotations, and automated Bill of Materials
Utilize advanced tools: configurations, design tables, sheet metal features, weldments, and basic surfacing
Program Overview
Module 1: SolidWorks 2021 Introduction & UI
⏳ 1 hour
Topics: Ribbon interface enhancements, new PropertyManager layouts, context-sensitive tooltips
Hands-on: Customize your workspace and explore Dynamic Reference Visualization
Module 2: Sketching & Geometric Relations
⏳ 1.5 hours
Topics: Enhanced snapping, Arc Dimension tool, smart dimension improvements
Hands-on: Create a parametric sketch using relation aids and global variables
Module 3: Core 3D Features
⏳ 2 hours
Topics: Extrude Boss/Base, Revolve, Swept Boss, Lofted Boss, Cut-Extrude enhancements (Up to Surface)
Hands-on: Model a multi-feature bracket incorporating advanced cut options
Module 4: Assembly Modeling
⏳ 1.5 hours
Topics: Pattern-driven Component Pattern, improved mate diagnostics, Defeature tool for large assemblies
Hands-on: Build a gearbox assembly, apply mates, and simplify with Defeature for faster performance
Module 5: Drawing & Detailing
⏳ 1.5 hours
Topics: Detailing mode for large drawings, Automate Hole Callouts, Model-Based Definition (MBD) enhancements
Hands-on: Create a detailed drawing set with custom tables and MBD annotations
Module 6: Configurations & Design Tables
⏳ 1 hour
Topics: Treehouse-based configuration management, Linked design tables, Global variable-driven designs
Hands-on: Set up a family of parts (e.g., flanges) with varying dimensions via design tables
Module 7: Sheet Metal & Weldments
⏳ 1 hour
Topics: Edge flanges, jog slots, improved corner trimming, 3D Sketch-driven Weldment profiles
Hands-on: Design a sheet-metal chassis and add weldment members for framing
Module 8: Surfacing & Render
⏳ 1 hour
Topics: Filled Surface enhancements, zebra stripe analysis, basic photorealistic rendering with PhotoView 360
Hands-on: Create a smooth freeform surface and render a product shot
Module 9: Final Project – Complete Product Design
⏳ 3 hours
Topics: End-to-end workflow: concept sketch to assembly to drawing documentation
Hands-on: Design, assemble, and document a consumer product (e.g., Bluetooth speaker) applying all learned techniques
